Work Done By A Force Acting on The Piston

Let's discuss a problem and find out the work done by a force acting on the piston. First, try the problem and then read the solution.

The Problem:

A cylinder filled with water of volume (V) is fitted with a piston and placed horizontally. There is a hole of cross-sectional area (s) at the other end of the cylinder, (s) being much smaller than the cross-sectional area of the piston. Show that the work to be done by a constant force acting on the piston to squeeze all water from the cylinder in time (t) is given by $$ W=\frac{\rho V^3}{2s^2t^2}$$ where (\rho) is the density of water.

Solution:

The volume of water flowing out per second $$ Q=sv$$
where (v) is the speed of sound and (s) is the cross-sectional area.
Volume flowing out $$ V=Qt=svt$$ $$ \frac{ \rho v^2}{2}=P$$$$= \frac{F}{A}$$ $$=\frac{FL}{AL}$$ $$ =\frac{W}{V}$$
where (L) is the length of the cylinder and (W) is the work done.
$$ W=\frac{1}{2}\frac{\rho V^3}{s^2t^2}$$

More Problem: https://www.cheenta.com/velocity-of-efflux-at-the-bottom-of-a-tank/
