Test of Mathematics Solution Subjective 128 - Graphing min value function

Test of Mathematics at the 10+2 Level

This is a Test of Mathematics Solution Subjective 128 (from ISI Entrance). The book, Test of Mathematics at 10+2 Level is Published by East West Press. This problem book is indispensable for the preparation of I.S.I. B.Stat and B.Math Entrance.


Problem

 Draw the graph (on plain paper) of f(x)= min { |x| -1, |x-1| - 1, |x-2|-1}


Solution

 The easiest way to solve this problem is to draw the graph of all these three pieces of functions mentioned, and pick ones which are minimum.

Graph of y = |x| is same as, y =  x, where x is non negative. For negative values of x, it is the graph of y = x reflected about x axis.

Screen Shot 2015-11-19 at 9.29.26 PM

Now we apply transformations to find the remaining graphs.

  • Graph of y = |x|-1 can be found by lowering the graph of y = |x| by 1 unit along y axis.
    Screen Shot 2015-11-19 at 9.30.31 PM
  • Graph of y = |x-1| - 1 can be found by first shift the graph of y = |x| along positive direction of x axis by 1 unit, and then lowering it by 1 unit along y axis.
    Screen Shot 2015-11-19 at 9.30.43 PM
  • Graph of y = |x-2| - 1 can be found by first shift the graph of y = |x| along positive direction of x axis by 2 unit, and then lowering it by 1 unit along y axis.

Read More...
